BCR Series reads all malaysia identification (MyKad reader) and supports MyKad EBA - Enhanced Biometric Access


Product Comparison

BCR

BCR230BT

Contact Card
Fingerprint Sensor

MyKad Reader that’s supports MyKad EBA,
Enhanced Biometric Access



BCR200DTP

Contact Card
Fingerprint Sensor

Available in:
Bluetooth
or Desktop



BCR250BT

Contactless Card
Fingerprint Sensor
Bluetooth

BCR Medium Res-2.png

BCR300c

Contact Card
Contactless Card
Fingerprint Sensor
USB 2.0


Ideal for

BCR Series Product Page_BCR Deployment.png

Specification

Fingerprint Sensor

  • Sensor
    Optical Biometric Sensor

  • Resolution
    500dpi @ 8-bit per pixel

  • Active Area(mm)
    14 x 22

  • Supported Template
    Sagem Algorithm

  • Supported Standard
    ISO 19794 - 2

  • Template Format
    ANSI 378, RAW/Bitmap, WSQ (License required)

  • Storage Capacity
    Up to 1000 Templates

  • Fingerprint Search
    1:1 & 1:N

  • Verification Time
    < 0.8 second

  • Identification Time
    < 1 second

Contact Card Reader

  • Standard
    ISO/IEC 7816 Part 1,2,3

  • Card Slot
    1 x ID-1 Card slot, 1 x ID-0 SAM slot

  • Card Type
    Class A & B / Class A, B & C

System

  • Host Operating System Requirement
    Window 8.1/8/7/Vista XP (Desktop)

  • Programming Language
    C++ Programming, .NET Programming (VB or C#)

Human Interfaces

  • Status Indicator
    LED x 2

Communication Interface

  • USB
    USB 2.0

  • Environmental Operating Temperature
    -10°C to +50°C

  • Humidity
    5% to 95% RH, Non-condensing

Power

  • Current
    180 mA

  • Battery
    USB bus-powered

Mechanical

  • Dimension (mm)
    108 (L) x 58 (W) x 30(H)

  • Weight (g)
    83
