DPS Series Product Page_Product Banner.png
DPS Series Product Page_Product Description .png

Product Comparison

DPS Series Product Page_DPS700_Description.png
DPS Series Product Page_Product Comparison.png

Ideal For

DPS Series Product Page_Deployment Industry.png

Specification

Optical Specification

  • Illumination
    UV
    Visible (White)
    Infrared (B900)
    OVD

  • Image Resolution (PPI)
    475-500

  • Image Color Depth
    24 bit / pixel RGB ; 8 bit / pixel IR Image

  • Optical System (DSP)
    Dual Camera Module / Single Camera Module

  • Scanning Area (mm)
    129 x 87 (Full Page) / 125 x 55 (Half Page)

  • Image Format
    BMP
    JPG
    JPG2000
    PNG


MRZ OCR Scanner

  • Standard
    ICAO 9303 Compliant


Contact Card Reader

  • Standard
    ISO / IEC Standard 7816
    Part 1,2,3

  • ID-1 Card Slot x 1

  • ID - 0 Sam Slot x 2

  • Card Type
    Class A, B


Contactless Card Reader

  • Standard
    ISO 14443 A / B Part 1, 2, 3, 4, MIFARE™ Classic, ICAO 9303 Compliant

  • Card Transmission Rate
    848 kbps

  • Security
    AA (Active Authentication
    PA (Passive Authentication)
    BAC (Basic Access Control)


Barcode Reader

  • Standard
    Maxicode, LP Code
    Chinese - sensible Code
    UPC-A, EAN8, EAN13, Code39
    Code128 and ITF, PDF417, Data Matrix
    QR Code, Aztec Code


Electrical

  • Power
    12 V DC - Current (Standby): 1010mA / 900mA
    USB bus-powered - Current (Standby): 500mA

  • Communication Interface
    USB downstream 5V x 1
    USB Client 2.0 High Speed
    LED x 3


Software Specification

  • Supported Operating System
    Windows® 8.1 / 7/ Vista / XP

  • Programming Languages
    VB.NET, C#.NET, C/C++, VB6
    Java, Delphi


Mechanical

  • Dimension (mm) & Weight (kg)
    DPS700 - 271 (L) x 229 (W) x 342 (H), 5.0KG
    DPS550 - 241 (L) x 195 (W) x 187 (H), 3.4KG
    DPS500 - 241 (L) x 180 (W) x 187 (H), 3.4KG
    DPS200 - 130 (L) x 152 (W) x 82 (H), 0.6KG
    DPS100 - 130 (L) x 152 (W) x 82 (H), 0.6KG


Environment

  • Operating Temperature
    5˚C to 45˚C

  • Humidity
    0% to 95% RH, Non-Condensing
