Ideal for

HPT 600 Product Page_HPT Deploy Industry.png


Specification

System

  • Microprocessor
    Intel® ATOMTM Z510, 1.1GHz

  • Memory
    1GB SDRAM, 16GB Flash

  • Memory Expansion
    1 x micro-SD Memory Slot (Support up to 32GB)

  • Operating System
    Windows® Embedded Standard 7

  • Programming Language
    C++ Programming, .NET Programming in Microsoft® Visual 2005, 2008

MRZ OCR Scanner

  • Standard
    ICAO 9303 Compliant

  • MRZ Swipe Direction Data Source
    Bi-direction

  • Machine Readable Passports (MRP)
    2 lines of 44 characters

  • Machine Readable Visas (MRV)
    - 2 lines of 44 characters (full size)
    – 2 lines of 36 characters (size II)

  • Machine Readable Travel Cards
    – 2 lines of 36 characters (size II)
    – 3 lines of 30 characters (size I)

Contactless Reader

  • Standard
    ICAO 9303 Compliant
    ISO/IEC 14443 A/B Part 1, 2, 3, 4

  • Communication Speed
    Up to 848 kbps (Card Type Dependent)

Contact Card Reader

  • Standard
    ISO/IEC 7816 Part 1, 2, 3 (T=0, T=1)

  • Card Slot
    1 x ID-1 Card slot, 2 x ID-0 SAM slots (Optional)

  • Communication Speed
    115.2 kbps (max)

  • Card Type
    Class A, A/B

Camera

  • Resolution
    2 Megapixels with Auto Focus

  • Flash
    LED

Fingerprint Sensor

  • Sensor
    Optical Sensor

  • Resolution (dpi)
    500

  • Active Area (mm)
    14 x 22

  • Supported Template
    Sagem Algorithm

  • Template Formats
    Morpho Proprietary, ISO 19794-2, ANSI378, RAW/Bitmap, WSQ Output (Optional)

GPS

  • Receiver Type
    50 Channels
    GPS L1 Frequency, C/A Code
    SBAS: WAAS, EGNOS, MSAS, GAGAN

Human Interfaces

  • Display
    5” Transflective TFT Color Touch Screen with Backlight (800 x 480)

  • Keypad
    64 Buttons QWERTY Keypad

  • Audio
    Built-in Mono Speaker, Head Phone Jack

Communication Interface

  • Bluetooth
    Bluetooth Class II, Version 3.0+HS

  • Wireless LAN
    IEEE 802.11 b/g Wi-Fi

  • Network
    3.5G - HSDPA 7.2 Mbps Downlink
    HSUPA 5.76 Mbps Uplink
    3G - W-CDMA (2100, 1900, 900 MHz)
    2G/2.5G - GSM / GP RS / EDGE
    (1900, 1800, 900, 850 MHz)

  • USB
    USB 2.0 (External Accessible)

  • LAN
    RJ45 Socket (Built-in 10/100 Mbps)

Environmental

  • Operating Temperature
    -10°C to +50°C

  • Storage Temperature
    -20°C to +60°C

  • Humidity
    5% to 90% RH, Non-condensing

  • Water & Dust Protection
    IP54

Power

  • Battery
    Rechargeable 7.4V 4000mAh
    Li-Polymer Battery
    Rechargeable 7.4V 8000mAh
    Li-Polymer Battery (Optional)

  • AC Input
    100-240 VAC, 50/60 Hz

  • DC Output
    12V, 3A

Mechanical

  • Dimension (mm)
    326 (L) x 140 (W) x 66 (H)

  • Weight (kg)
    ~ 0.9
